13-22
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 13 Configuring CEF for PFC2 and PFC3A
Configuring CEF for PFC2/PFC3A on the Switch
This example shows how to display the IP multicast routing table:
Router# show ip mroute 239.252.1.1
IP Multicast Routing Table
Flags:D - Dense, S - Sparse, C - Connected, L - Local, P - Pruned
R - RP-bit set, F - Register flag, T - SPT-bit set, J - Join SPT
M - MSDP created entry, X - Proxy Join Timer Running
A - Advertised via MSDP
Outgoing interface flags:H - Hardware switched
Timers:Uptime/Expires
Interface state:Interface, Next-Hop or VCD, State/Mode
(*, 239.252.1.1), 04:04:59/00:02:59, RP 80.0.0.2, flags:SJ
Incoming interface:Vlan800, RPF nbr 80.0.0.2
Outgoing interface list:
Vlan10, Forward/Dense, 01:29:57/00:00:00, H
(22.0.0.10, 239.252.1.1), 00:00:19/00:02:41, flags:JT
Incoming interface:Vlan800, RPF nbr 80.0.0.2, RPF-MFD
Outgoing interface list:
Vlan10, Forward/Dense, 00:00:19/00:00:00, H
Displaying IP Multicast Details
The show mls ip multicast command displays detailed information about IP MMLS.
To display detailed MMLS information on MSFC2/MSFC3, perform one of these tasks:
This example shows how to display IP MMLS statistics on MSFC2/MSFC3:
Router# show mls ip multicast statistics
MLS Multicast configuration and state:
Router Mac:0050.0f2d.9bfd, Router IP:1.12.123.234
MLS multicast operating state:ACTIVE
Maximum number of allowed outstanding messages:1
Maximum size reached from feQ:1
Feature Notification sent:5
Feature Notification Ack received:4
Unsolicited Feature Notification received:0
MSM sent:33
MSM ACK received:33
Delete notifications received:1
Flow Statistics messages received:248
Task Command
Display IP MMLS group information. Router# show mls ip multicast group group-address
[interface type number | statistics]
Display IP MMLS details for all
interfaces.
Router# show mls ip multicast interface type number
[statistics | summary]
Display a summary of IP MMLS
information.
Router# show mls ip multicast summary
Display IP MMLS statistics. Router# show mls ip multicast statistics
Display IP MMLS source information. Router# show mls ip multicast source ip-address
[interface type number | statistics]
