14-25
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 14 Configuring MLS
Configuring MLS
Displaying All MLS Entries
To display all the MLS entries (IP and IPX), perform this task in privileged mode:
This example shows how to display all the MLS entries (IP and IPX):
Console> (enable) show mls entry short
Destination-IP Source-IP Prot DstPrt SrcPrt Destination-Mac Vlan
--------------- --------------- ----- ------ ------ ----------------- ----
ESrc EDst SPort DPort Stat-Pkts Stat-Bytes Created LastUsed
---- ---- ----- ----- ---------- ------------ -------- --------
171.69.200.234 171.69.192.41 TCP* 6000 59181 00-60-70-6c-fc-22 4
ARPA SNAP 5/8 11/1 3152 347854 09:01:19 09:08:20
171.69.1.133 171.69.192.42 UDP 2049 41636 00-60-70-6c-fc-23 2
SNAP ARPA 5/8 1/1 2345 1234567 09:03:32 09:08:12
171.69.1.133 171.69.192.42 UDP 2049 41636 00-60-70-6c-fc-23 2
SNAP ARPA 5/8 1/1 2345 1234567 09:03:32 09:08:12
171.69.1.133 171.69.192.42 UDP 2049 41636 00-60-70-6c-fc-23 2
SNAP ARPA 5/8 1/1 2345 1234567 09:03:32 09:08:12
171.69.1.133 171.69.192.42 UDP 2049 41636 00-60-70-6c-fc-23 2
SNAP ARPA 5/8 1/1 2345 1234567 09:03:32 09:08:12
Total IP entries: 5
* indicates TCP flow has ended.
Destination-IPX Source-IPX-net Destination-Mac Vlan Port
Stat-Pkts Stat-Bytes
------------------------- -------------- ----------------- ---- -----
--------- -----------
BABE.0000.0000.0001 - 00-a0-c9-0a-89-1d 211 13/37
30230 1510775
201.00A0.2451.7423 - 00-a0-24-51-74-23 201 14/33
30256 31795084
501.0000.3100.0501 - 31-00-05-01-00-00 501 9/37
12121 323232
401.0000.0000.0401 - 00-00-04-01-00-00 401 3/1
4633 38676
Total IPX entries: 4
Console>
Displaying MLS Entries for a Specific IP Destination Address
To display the MLS entries for a specific destination IP address, perform this task in privileged mode:
Task Command
Display all the MLS entries. show mls entry [short | long]
Task Command
Display the MLS entries for the specified
destination IP address.
show mls entry ip destination [ip_addr]
