14-26
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 14 Configuring MLS
Configuring MLS
This example shows how to display the MLS entries for a specific destination IP address:
Console> (enable) show mls entry ip destination 172.20.22.14/24
Destination-IP Source-IP Prot DstPrt SrcPrt Destination-Mac Vlan
EDst ESrc DPort SPort Stat-Pkts Stat-Bytes Uptime Age
--------------- --------------- ----- ------ ------ ----------------- ----
---- ---- ------ ------ ---------- ----------- -------- --------
MSFC 172.20.25.1 (Module 15):
172.20.22.14 - - - - 00-60-70-6c-fc-22 4
ARPA ARPA 5/39 5/40 115 5290 00:12:20 00:00:04
MSFC 172.20.27.1 (Module 16):
Total entries:1
Console> (enable)
Displaying IPX MLS Entries for a Specific IPX Destination Address
To display the IPX MLS entries for a specific destination IPX address, perform this task in privileged
mode:
This example shows how to display the IPX MLS entries for a specific destination IPX address:
Console> (enable) show mls entry ipx destination 3E.0010.298a.0c00
Destination IPX Source IPX net Destination Mac Vlan Port
------------------------- -------------- ----------------- ---- -----
MSFC 22.1.0.56 (Module 15):
3E.0010.298a.0c00 13 00-00-00-00-00-09 26 4/7
Console> (enable)
Displaying MLS Entries for a Specific IP Source Address
To display the MLS entries for a specific source IP address, perform this task in privileged mode:
This example shows how to display the MLS entries for a specific source IP address:
Console> (enable) show mls entry ip source 10.0.2.15
Destination-IP Source-IP Prot DstPrt SrcPrt Destination-Mac Vlan
EDst ESrc DPort SPort Stat-Pkts Stat-Bytes Uptime Age
--------------- --------------- ----- ------ ------ ----------------- ----
---- ---- ------ ------ ---------- ----------- -------- --------
MSFC 172.20.25.1 (Module 15):
172.20.22.14 10.0.2.15 TCP Telnet 37819 00-e0-4f-15-49-ff 51
ARPA ARPA 5/39 5/40 115 5290 00:12:20 00:00:04
MSFC 172.20.27.1 (Module 16):
Total entries:1
Console> (enable)
Task Command
Display the IPX MLS entries for a specific
destination IPX address
(net_address.node_address).
show mls entry ipx destination ipx_addr
Task Command
Display the MLS entries for the specified
source IP address.
show mls entry ip source [ip_addr]
