14-38
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 14 Configuring MLS
Configuring MLS
Displaying IP MMLS Configuration Information
The show mls multicast command displays the global IP MMLS configuration information and the state
of the participating MSFCs.
To display the global IP MMLS configuration information, perform this task:
This example shows how to display the global IP MMLS configuration information:
Console> (enable) show mls multicast
Admin Status: Enabled
Operational Status: Active
Configured flow mask is {Destination-source-vlan flow}
Active Entries = 10
Router include list :
1.1.9.254 (Active)
1.1.5.252 (Active)
Console> (enable)
Displaying IP MMLS Statistics
The show mls multicast statistics command displays the IP MMLS statistics for the multicast MSFCs.
To display the IP MMLS statistics for the multicast MSFCs, perform this task:
This example shows how to display the IP MMLS statistics for the multicast MSFCs:
Console (enable) show mls multicast statistics
Router IP Router Name Router MAC
-------------------------------------------------------
1.1.9.254 ? 00-50-0f-06-3c-a0
Transmit:
Delete Notifications: 23
Acknowledgements: 92
Flow Statistics: 56
Receive:
Open Connection Requests: 1
Keep Alive Messages: 72
Shortcut Messages: 19
Shortcut Install TLV: 8
Selective Delete TLV: 4
Group Delete TLV: 0
Update TLV: 3
Input VLAN Delete TLV: 0
Output VLAN Delete TLV: 0
Global Delete TLV: 0
MFD Install TLV: 7
MFD Delete TLV: 0
Task Command
Display the global IP MMLS configuration
information.
show mls multicast
Task Command
Display the IP multicast MSFC statistics. show mls multicast statistics [ip_addr]
