20-66
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 20 Checking Status and Connectivity
Configuring the Ethernet Local Management Interface
This example shows how to set the Ethernet EVC ID as EVC1 for module 7, port 1:
Console> (enable) set port ethernet-evc 7/1 EVC1
EVC1 is associated to port 7/1.
Console> (enable
Displaying an EVC
To display the EVCs configured on a device, perform this task in privileged mode:
These examples show how to display EVCs configured on the device:
Console> (enable) show ethernet-evc
St EVC Id CE-Vlan
--- ---------- -------------------------------
A EVC1 10
A EVC2 20
Key: St=Status, A=Active, P=Partially Active, I=Inactive, ?=ELMI Link Down
Console> (enable) show ethernet-evc detail
EVC Id: EVC1
EVC Type: P-P
EVC Status: Active
EVC Uni Count: 2
Number of Remote UNIs up: 1
Number of Local UNIs up: 1
CFM Service Maintenance Domain: ELMI
CFM Service Maintenance Name: CFM1
EVC CE-Vlan Mapping: 10
Ports associated to this EVC: 7/1
Remote UNI Details:
UNI Id UNI Status Port
-------------- ------------ -----------
SANFRANCISCO Up 4/47
EVC Id: EVC2
EVC Type: P-P
EVC Status: Inactive
EVC Uni Count: 2
Number of Remote UNIs up: 0
Number of Local UNIs up: 1
CFM Service Maintenance Domain: SJC
CFM Service Maintenance Name: CFM2
EVC CE-Vlan Mapping: 20
Ports associated to this EVC: 7/1
Displaying CE-VLAN/ EVC
To display the CE-VLAN/EVC mapping configured for the port, perform this task in privileged mode:
Task Command
Display EVCs configured on a device. show ethernet-evc {[detail] | evc_id [detail]}
