Chapter 20 Checking Status and Connectivity
Configuring the Ethernet Local Management Interface
These examples show how to display the CE-VLAN/EVC mapping configured for module 7, port 1:
Console>(enable) show port ethernet-evc 7/1
UNI Id: PE-CUSTA-PORT1
St EVC Id CE-Vlan
------ -------------- ----------
?A EVC1 10
?A EVC2 20
Key: St=Status, A=Active, P=Partially Active, I=Inactive, ?=ELMI Link Down
Console> (enable) show port ethernet-evc 7/1 EVC1 detail
Port: 7/1
EVC Id: EVC1
Time since Last Full Report: Never
Ether LMI Link Status: Down
UNI Id: SANJOSE
UNI Status: Up
CE-VLAN/EVC Map Type: multiplex
CE-VLAN: 10
EVC Status: Inactive
EVC Type: Point-to-Point
Remote UNI Count: Configured = 1, Active = 0
Displaying ELMI Statistics and Configuration
To display ELMI statistics and ELMI parameters, perform one of these tasks in privileged mode:
This example shows how to display the ELMI statistics and configuration for module 7, port 1:
Console> (enable) show port ethernet-lmi 7/1 statistics
E-LMI statistics for port 7/1
Ethernet LMI Link Status: Up
UNI Status: Up
UNI Id: PE1-CustA-Port1
Reliability Errors:
Status Enq Timeouts 0 Invalid Sequence Number 0
Protocol Errors:
Invalid Protocol Version 0 Invalid EVC Reference Id 0
Invalid Message Type 0 Out of sequence IE 0
Duplicated IE 0 Mandatory IE missing 0
Invalid Mandatory IE 0 Invalid non-mandatory IE 0
Unrecognized IE 0 Unexpected IE 0
Last Full Status Enq Rcvd 00:00:10 Last Full Status Sent 00:00:10
Last Status Check Enq Rcvd 00:00:00 Last Status Check Sent 00:00:00
Last clearing of counters never
Console> (enable) show port ethernet-lmi 7/1 config
Task Command
Display the CE-VLAN/EVC mapping. show port ethernet-evc mod/port {[detail] |
evc-id [detail]}
Task Command
Display ELMI statistics. show port ethernet-lmi mod/port statistics
Display the ELMI configuration. show port ethernet-lmi mod/port config
