20-76
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 20 Checking Status and Connectivity
Digital Optical Monitoring
This example shows how to display port transceiver information:
Console> show port transceiver 2/1
sh port transceiver 5/1
Transceiver monitoring is enabled.
Monitor interval is set to 1 minute
ITU Channel not available (1550 nm)
## : high alarm, # : high warning, @ : low warning, @@ : low alarm.
NA or N/A: not applicable, Tx: transmit, Rx: receive.
mA: milliamperes, dBm: decibels (milliwatts).
Optical Optical
Temperature Voltage Current Tx Power Rx Power
Port (Celsius) (Volts) (mA) (dBm) (dBm)
----- ----------- --------- ------------ ------------ ------------
5/1 29.2 N/A 102.5 0.9 @@ -31.0
Displaying Port Transceiver Configuration Information
To display port transceiver configuration information, perform this task in enabled mode:
This example shows how to display port transceiver configuration information:
Console> show port transceiver 3/1 config
Transceiver monitoring is disabled.
Monitor interval is set to 1 minute.
Transmit Power (dBm)
High Alarm High Warn Low Warn Low Alarm
Threshold Threshold Threshold Threshold
Port Value Severity Value Severity Value Severity Value Severity
----- ------- ---------- ------- ---------- ------- ---------- ------- -----
3/1 default critical default critical default critical default critical
Receiver Power (dBm)
High Alarm High Warn Low Warn Low Alarm
Threshold Threshold Threshold Threshold
Port Value Severity Value Severity Value Severity Value Severity
----- ------- ---------- ------- ---------- ------- ---------- ------- -----
3/1 default critical default critical default critical default critical
Temperature (Celsius)
High Alarm High Warn Low Warn Low Alarm
Threshold Threshold Threshold Threshold
Port Value Severity Value Severity Value Severity Value Severity
----- ------- ---------- ------- ---------- ------- ---------- ------- ------
3/1 default critical default critical default critical default critical
Voltage (volts)
High Alarm High Warn Low Warn Low Alarm
Threshold Threshold Threshold Threshold
Port Value Severity Value Severity Value Severity Value Severity
----- ------- ---------- ------- ---------- ------- ---------- ------- -----
3/1 default critical default critical default critical default critical
Task Command
Display port transceiver configuration
information.
show port transceiver mod/port config
