COBHAM GR712RC User Manual

GR712RC-UM, Jun 2017, Version 2.9 9 www.cobham.com/gaisler
GR712RC
1.4 Interrupts
The following table specifies the interrupt assignment for the GR712RC.
The interrupts are routed to the IRQMP interrupt controller and forwarded to the LEON3FT proces-
sors. Interrupt 16-31 are generated as interrupt 12 and for those interrupts a chained interrupt handler
is used.
1.5 GRLIB IP cores
The GR712RC uses the following cores from the GRLIB IP library:
TABLE 2. Interrupt assignment
Core Interrupt # Function
AHBSTAT 1 AHB bus error
APBUART - 0 2 UART1 RX/TX interrupt
GRGPIO - 1 to 2 1-15 External I/O interrupt (3 & 4 are GPIO only)
CANOC 5-6 OCCAN interrupt (core 1 - 2)
GRTIMER 7 GRTIMER timer underflow interrupt
GPTIMER 8-11 GPTIMER timer underflow interrupts
IRQMP 12 IRQMP extended interrupt
SPICTRL, SLINK 13 SPI and SLINK interrupt
B1553BRM, GRETH, GRTC 14 1553, Ethernet, and Telecommand interrupt
ASCS 16 ASCS interrupt
APBUART - 1to 5 17-21 UART2-6 RX/TX interrupt
GRSPW2 - 0 to 5 22-27 SpaceWire 0-5 RX/TX data interrupt
I2CMST 28 I2C master interrupt
GRTM 29 Telemetry encoder interrupt
30 Telemetry encoder time strobe interrupt
TABLE 3. Used IP cores
Core Function Vendor ID Device ID
LEON3FT Fault tolerant SPARC V8 32-bit processor 0x01 0x053
DSU3 Debug support unit 0x01 0x004
IRQMP Interrupt controller 0x01 0x00D
APBCTRL AHB/APB Bridge 0x01 0x006
FTMCTRL 8/32-bit Memory controller with EDAC 0x01 0x054
AHBSTAT AHB failing address register 0x01 0x052
FTAHBRAM Fault tolerant on chip memory 0x01 0x050
AHBJTAG JTAG/AHB debug interface 0x01 0x01C
GRSPW2 SpaceWire link with DMA 0x01 0x029
B1553BRM MIL-STD1553B BC/RT/BM controller 0x01 0x072
CANOC OC CAN controller 0x01 0x019
GRETH 10/100 Ethernet MAC 0x01 0x01D
APBUART 8-bit UART with FIFO 0x01 0x00C
GPTIMER Modular timer unit 0x01 0x011
GRTIMER Modular timer unit with time latch capability 0x01 0x038
GRGPIO General purpose I/O port 0x01 0x01A
GRTC CCSDS Telecommand Decoder 0x01 0x031
GRTM CCSDS Telemetry Encoder 0x01 0x030
- Proprietary 0x01 0x080
CANMUX CAN bus multiplexer 0x01 0x081
