GR712RC-UM, Jun 2017, Version 2.9 183 www.cobham.com/gaisler
GR712RC
25.4 Signal definitions
The signals are described in table 202.
Table 201. TM data register
31 16 15 0
Rtmd
31:16 Reserved, always zero.
15:0 TM data. Received TM data is stored here. (Read only)
Table 202.Signal definitions
Signal name Type Function Active
A16DASA, A16DASB Input ASCS slave data in -
A16MCS Output TC start/stop signal Logical 1
A16HS Output Serial clock used for TC/TM Logical 1
A16DCS Output ASCS slave data out -
A16MAS Output TM start/stop signal Logical 1
A61ETR Output Synchronization signal Logical 1
