COBHAM GR712RC User Manual

GR712RC-UM, Jun 2017, Version 2.9 95 www.cobham.com/gaisler
GR712RC
TABLE 67. GPIO ports and signals
GPIO port Register bit no. Pin function External pin name InterruptDirection
GRGPIO - 1 0 GPIO[0] SWMX[3] In
GRGPIO - 1 1 GPIO[1] SWMX[4] 1 In/Out
GRGPIO - 1 2 GPIO[2] SWMX[5] 2 In
GRGPIO - 1 3 GPIO[3] SWMX[6] 3 In/Out
GRGPIO - 1 4 GPIO[4] SWMX[7] 4 In
GRGPIO - 1 5 GPIO[5] SWMX[8] 5 In/Out
GRGPIO - 1 6 GPIO[6] SWMX[9] 6 In
GRGPIO - 1 7 GPIO[7] SWMX[10] 7 In/Out
GRGPIO - 1 8 GPIO[8] SWMX[11] 8 In
GRGPIO - 1 9 GPIO[9] SWMX[12] 9 In/Out
GRGPIO - 1 10 GPIO[10] SWMX[13] 10 In/Out
GRGPIO - 1 11 GPIO[11] SWMX[14] 11 In
GRGPIO - 1 12 GPIO[12] SWMX[15] 12 In
GRGPIO - 1 13 GPIO[13] SWMX[16] 13 In/Out
GRGPIO - 1 14 GPIO[14] SWMX[17] 14 In/Out
GRGPIO - 1 15 GPIO[15] SWMX[18] 15 In
GRGPIO - 1 16 GPIO[16] SWMX[19] In
GRGPIO - 1 17 GPIO[17] SWMX[20] In/Out
GRGPIO - 1 18 GPIO[18] SWMX[21] In/Out
GRGPIO - 1 19 GPIO[19] SWMX[22] In
GRGPIO - 1 20 GPIO[20] SWMX[23] In
GRGPIO - 1 21 GPIO[21] SWMX[24] In/Out
GRGPIO - 1 22 GPIO[22] SWMX[25] In/Out
GRGPIO - 1 23 GPIO[23] SWMX[26] In
GRGPIO - 1 24 GPIO[24] SWMX[27] In
GRGPIO - 1 25 GPIO[25] SWMX[28] In/Out
GRGPIO - 1 26 GPIO[26] SWMX[29] In/Out
GRGPIO - 1 27 GPIO[27] SWMX[30] In
GRGPIO - 1 28 GPIO[28] SWMX[31] In
GRGPIO - 1 29 GPIO[29] SWMX[32] In/Out
GRGPIO - 1 30 GPIO[30] SWMX[33] In/Out
GRGPIO - 1 31 GPIO[31] SWMX[34] In
GRGPIO - 2 0 GPIO[32] SWMX[35] In
GRGPIO - 2 1 GPIO[33] SWMX[36] 1 In/Out
GRGPIO - 2 2 GPIO[34] SWMX[37] 2 In/Out
GRGPIO - 2 3 GPIO[35] SWMX[38] 3 In
GRGPIO - 2 4 GPIO[36] SWMX[39] 4 In
GRGPIO - 2 5 GPIO[37] SWMX[40] 5 In/Out
GRGPIO - 2 6 GPIO[38] SWMX[41] 6 In/Out
GRGPIO - 2 7 GPIO[39] SWMX[42] 7 In
GRGPIO - 2 8 GPIO[40] SWMX[43] 8 In/Out
GRGPIO - 2 9 GPIO[41] SWMX[44] 9 In/Out
GRGPIO - 2 10 GPIO[42] SWMX[45] 10 In/Out
GRGPIO - 2 11 GPIO[43] SWMX[46] 11 In
GRGPIO - 2 12 GPIO[44] SWMX[47] 12 In
GRGPIO - 2 13 GPIO[45] SWMX[48] 13 In/Out
GRGPIO - 2 14 GPIO[46] SWMX[49] 14 In/Out
GRGPIO - 2 15 GPIO[47] SWMX[50] 15 In
GRGPIO - 2 16 GPIO[48] SWMX[51] In
GRGPIO - 2 17 GPIO[49] SWMX[52] In/Out
GRGPIO - 2 18 GPIO[50] SWMX[53] In/Out
