9.3 Binary inputs list
9.3.1 Not used
Binary input has no function. Use this option when binary input is not connected.
9.3.2 Rem start/stop
Binary input is used for external request for engine run in AUT mode only.
9.3.3 Emergency stop
If the input is opened, shut down is immediately activated. Input is inverted (normally closed) in default
configuration.
HINT
In case of controller hardware or software fail, safe stop of the engine doesn’t have to be ensured. To
back-up the Emergency stop function it is recommended to connect separate circuit for disconnection
of Fuel solenoid and Starter signals.
9.3.4 Sprinkler
If the input is closed all alarms are disabled except the binary input Emergency stop and "engine
overspeed protection".
 all InteliDrive Lite alarms are detected,
 InteliDrive Lite front panel RED LED blinks or lights,
 Alarm is recorded on the InteliDrive Lite alarm list screen,
 BUT engine remains running.
HINT
Warning SprinklActive is indicated in the Alarm list if sprinkler mode active to inform the operator that
the engine is not protected.
9.3.5 Access lock
If the input is closed, no setpoints can be adjusted from controller front panel and engine mode (OFF-
MAN-AUT) cannot be changed.
HINT
Access lock does not protect setpoints and mode changing from LiteEdit. To avoid unqualified
changes the selected setpoints can be password protected.
9.3.6 Remote OFF
If closed, InteliDrive Lite is switched to OFF mode (there are three modes OFF-MAN-AUT). When
opens controller is switched back to previous mode.
HINT
This binary input should be connected to schedule timer switch, to avoid start of engine.
9.3.7 Remote MAN
If the input is active, MAN mode is forced to the controller independently on the position of the MODE
selector.
