ComAp InteliDrive Lite Reference Guide

InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
127
The output opens, if
 alarm is not active and
 FAULT RESET is pressed
10.2.40 DEF Tank Level
Output closes if the value DEF Tank Level drops under 10%, this level is adjustable in Engine
protect: DEF Level Min.
Outup opens if the value DEF Tank Level exceeds 90%. This upper limit is adjusted in Engine
protect: DEF Level Max.
HINT
This output is working only under condition ECU is configured and engine is in running state.
10.2.41 BI1, BI2, BI3, BI4, BI5, BI6, BI7, BI8, BI9, BI10 - stat
In case the binary input is configured to any control function, the binary output depicts the state of the
binary input. BI1, BI2, BI3, BI4, BI5, BI6 are assigned for controller binary inputs, BI7, BI8, BI9, BI10
are assigned for IL-NT IO1 optional card.
10.2.42 CtrlHeartBeat
The output signalizes watchdog reset. In a healthy state it flashes at 500ms : 500ms rate. It stops
flashing when the unit reset occurs and the new controller start-up fails.
10.2.43 BIO8 1, 2, 3, 4, 5, 6, 7, 8 Status
In case the assigned binary input of IL-NT BIO8 optional card is configured to any control function, the
output propagates the state of the input.
HINT
These binary outputs are possible to configure only if the IL-NT-BIO8 is configured.
10.2.44 Wrn AIN4, AIN5, AIN6, AIN7, AIN8, AIN9
Output closes if the warning alarms for AIN4, AIN5, AIN6, AIN7, AIN8, AIN9 activates.
The output opens, if
 alarm is not active and
 FAULT RESET is pressed
10.2.45 Sd AIN4, AIN5, AIN6, AIN7, AIN8, AIN9
Output closes if the shutdown alarms for AIN4, AIN5, AIN6, AIN7, AIN8, AIN9 activates.
The output opens, if
 alarm is not active and
 FAULT RESET is pressed
