ComAp InteliDrive Lite Reference Guide

InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
92
7.7.2 BIN6 delay [s]
Specific protection delay is possible to use on Binary Input 6. Delay is active for Wrn or Sd protection
only - not for functions like Rem Start/Stop. Protection delay is active for both Binary input NO / NC
configuration. BIN6 del starts after Eng prot del when BI6 protection is configured “Running only”.
Step: 1s
Range: 0 - 300s
Default: 1s
7.7.3 Horn timeout [s]
Max time limit of horn sounding. Set to zero if you want to leave the output HORN open. Horn timeout
starts again from the beginning if a new alarm appears before previous Horn timeout has elapsed.
Step: 1s
Range: 0 - 600s
Default: 10s
7.7.4 StartOverspeed
Limit for engine ShutDown overspeed protection. Protection is active during start process of the
engine and Idle time.
Step: 1%
Range: 50 - 150%
Default: 120%
HINT
The engine can spasmodically reach higher than Overspeed level during start, but for normal running
state would be this protection too high. This setpoint allows the overspeed protection during irregular
starting condition.
7.7.5 Overspeed [%]
Limit for engine ShutDown overspeed protection.
Step: 1% of nominal RPM
Range: 50 - 150%
Default: 115%
7.7.6 Underspeed [%]
Limit for Warning Underspeed protection. Active protection is indicated as “Wrn Underspeed” in Alarm
list. Under speed Warning protection is inactive 5s after RPM is over Engine params: Starting RPM
and during the Idle time.
The “Ready to load” output is deactivated when Wrn underspeed protection is active and needs the
Fault reset for activation after RPM is over Underspeed limit.
Step: 1% of nominal RPM
Range: Starting RPM - 100%
Default: 25%
