ComAp InteliDrive Lite Reference Guide

InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
128
10.2.46 ECU CommOK
If the ECU is not communicating and all values from ECU show #### the output is not active. If the
ECU communicates the output is active.
10.2.47 ECU CommError
The output is an inversion of binary output ECU CommOK, i.e. the output is closed when ECU is not
communicating and all values from ECU show #####.
10.2.48 ECU YellowLamp
The output copies warning information from ECU.
10.2.49 ECU RedLamp
The output copies shutdown information from ECU.
10.2.50 ECU PwrRelay
The output closes at the beginning of prestart and opens if the engine shall be stopped.
HINT
ECU binary outputs are possible to configure only if ECU is configured.
10.2.51 Timer1
Output activates when Timer1 is active. Simultaneously the engine is started when is in AUT mode.
10.2.52 Timer2
Output activates when Timer2 is active. Simultaneously the engine is started when is in AUT mode.
10.2.53 Glow plugs
The output closes prior to the engine start (Prestart) and opens when Starting RPM speed is reached.
During repeated crank attempts the output is opened.
10.2.54 Conveyor
Binary output function of Conveyor. See Binary input Conveyor.
10.2.55 SpeedSwitch
Binary output from Speed switch comparator – see Regulator setpoint group.
10.2.56 LoadSwitch
Binary output from Load switch comparator – see Load limit setpoint group.
