ComAp InteliDrive Lite Reference Guide

InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
78
Range: 5 – 1500RPM
Default value: 350RPM
RPM meas fail indication:
Can appears during "Cranking state" i.e. Starter (or J1939 Start command) is activated then one
running condition was detected (D+ was activated or (POil > Starting POil) condition was filled) - i.e.
Starter was switched off based on previous condition and within time (Cranking time and fix 5s)
minimum RPM does not appear (RPM > Starting RPM), then is activated RPM meas fail.
7.4.2 Starting POil [Bar]
Controller stops cranking (starter goes OFF) when Oil Pressure (typically measured on AIN1) is over
Starting POil.
NOTE:
Oil Pressure can be also measured on binary sensor. Then is necessary adjust AIN1 as Binary input
and Starting POil=1.
Step: 0.1Bar
Range: 0.0 – 10.0Bar
Default value: 4.5Bar
HINT
There are three conditions for stop cranking: Starting RPM (just in case the Gear teeth > 0),
StartingPOil and D+ (if enabled). Starter goes off when any of these conditions is valid.
7.4.3 Prestart time [s]
Time of the PRESTART output closed prior to the engine start – i.e. before the binary outputs Fuel
solenoid and Starter are closed and opens when Starting RPM speed is reached. Set to zero if you
want to leave the output PRESTART opened.
Step: 1s
Range: 0 - 600s
Default value: 2s
7.4.4 Preglow time [s]
Time of the PREGLOW output closed prior to the engine start. Set to zero if you want to leave the
output PREGLOW opened.
HINT
Function with shorter period (Prestart time or Preglow time) starts later to finish both in the same time
– when Starting RPM speed is reached.
Step: 1s
Range: 0 - 600s
Default value: 0s
7.4.5 MaxCrank time [s]
This setpoint is giving maximum time limit of engine cranking.
Step: 1s
Range: 1 - 60s
