ComAp InteliDrive Lite Reference Guide

InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
123
10.2.11 Air valves
Output closes together with Prestart and opens after the engine is stopped.
Stopped engine conditions: RPM = 0, Engine params: Starting Poil, D+function (if enabled).
10.2.12 Alarm
The output closes if:
 any warning, cooldown or shutdown comes up or
 the engine malfunctions
The output opens if
 FAULT RESET is pressed
The output closes again if a new fault comes up.
10.2.13 Horn
The output closes if:
 any warning or shutdown comes up or
 the engine malfunctions
The output opens if:
 FAULT RESET is pressed or
 HORN RESET is pressed or
 Max time of LBO HORN is exceeded (Horn timeout)
The output closes again if a new fault comes up.
10.2.14 Ready
The output is closed if following conditions are fulfilled:
 Engine is not running and
 No Shut down or Slow stop alarm is active
 Controller is not in OFF mode
10.2.15 Ready to load
The output is closed if engine is running and no alarm is active - it is possible to close load. The output
opens when Wrn Underspeed protection is active and during cooling state.
10.2.16 Running
Output closes if the engine is in Running state.
10.2.17 Cooling
The output closes when engine is in Cooling state.
10.2.18 Fault Reset
One second pulse as echo for panel Fault reset button.
