ComAp InteliDrive Lite Reference Guide

InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
98
7.7.30 AIN4 HighDel [s]
High level protection delay for Wrn and Sd of AIN4
Step: 1s
Range: 0 - 3600s
Default: 10s
NOTE:
Analog input 4 is fully configurable and it is voltage type of input with range 0-40V
7.7.31 AIN5 Level 1 [ ]
Warning limit level for AIN5
Step: 1
Range: 0 - 10000
Default: 20
7.7.32 AIN5 Level 2 [ ]
Shutdown limit level for AIN5
Step: 1
Range: 0 - 10000
Default: 10
7.7.33 AIN5 Del [s]
Delay for Wrn/Sd AIN5 alarm.
Step: 1s
Range: 0 - 3600s
Default: 10s
7.7.34 AIN5 Eval [NORMAL, CLASS C]
NORMAL: Protection behaves according to the standard configuration of Wrn/Sd alarm in
LiteEdit AINx configuration screen. Default state.
CLASS C: The protection is type “Running only” and does not depend on Running only tick in
LiteEdit AINx Alarm properties configuration window. Protection (Class C) is working
after AINx Del or sooner when appropriate value increases over AINx Wrn limit +3
seconds - after engine start. Warning/ShutdDown protection is activated with fix delay
0,5s.
HINT
Class C protection is working and corresponding setpoints are visible only when corresponding AIN is
configured in Modify->Alarm properties-> Direction-> Window prot.
