ComAp InteliDrive Lite Reference Guide

InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
122
10.2.4 Stop solenoid
The closed output energizes stop solenoid to stop the engine.
The output is active at least for Stop time, if the stop lasts longer; it stays active until all symptoms say
the engine is stopped.
The engine is stopped if:
 RPM < 2 and
 Oil pressure < Engine params: StartingPoil
HINT
The engine can be started anytime, if all symptoms say the engine is steady regardless of the fact the
Stop solenoid can still be active (in that case it is deactivated before cranking).
10.2.5 Stop Pulse
Output is active for 1 second after Stop solenoid output activation. This signal is sent to ECU in case
of engine stop request.
10.2.6 Ignition
The output closes after reaching value of CrankRPM, fixed 30RPM. The output opens after stopping of
the engine or in pause during repeated start.
10.2.7 Prestart
The output closes prior to the engine start (Prestart) and opens when Starting RPM speed is reached.
During repeated crank attempts the output is closed too.
The output could be used for pre-glow, pre-heat or prelubrication.
10.2.8 Preglow
The output closes prior to the engine start and opens when Starting RPM speed is reached. During
repeated crank attempts the output is closed too.
The output could be used for pre-glow or pre-heat.
10.2.9 Cooling pump
The output closes when engine starts and opens after Engine params: AfterCool time after stop of
the engine
10.2.10 Idle/Nominal
The output either follows the Nominal/Idle binary input or I/O button in MAN mode or follows the
engine state in AUT mode:
The output Idle/Nominal closes after the timer Idle time elapses. The Idle time counter starts to
countdown when Start speed reached. The Underspeed protection is not evaluated during idle time.
Start fail protection occurs if the RPM drop below 2RPM during idle state.
HINT
When LBI Nominal/Idle is configured (to a physical binary input), it has priority and the switching
between the nominal and the idle speed by I/0 button is blocked.
