InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
HINT
When opening connection to the controller its address has to correspond with the setting in PC tool.
7.3.2 COM1 Mode [DIRECT/MODEM/MODBUS/ECU LINK]
Communication protocol switches for the COM1 channel.
DIRECT: LiteEdit communication protocol via direct cable or AirGate, WebSupervisor
communication protocol via AirGate.
MODEM: LiteEdit communication protocol via modem.
MODBUS: Modbus protocol. See detailed description in InteliDrive Communication Guide.
ECU LINK: Protocol for communication with Cummins engines via Modbus.
HINT
For details on communication speed and other technical parameters please see chapter Technical
Data.
For detail description see chapter Modbus protocol.
7.3.3 COM2 Mode [DIRECT/MODBUS/ECU LINK]
Communication protocol switches for the COM2 channel, if dual communication module is plugged in.
DIRECT: LiteEdit communication protocol via direct cable.
MODBUS: Modbus protocol. See detailed description in InteliDrive Communication Guide
ECU LINK: Protocol for communication with Cummins engines via Modbus.
HINT
For details on communication speed and other technical parameters please see chapter Technical
Data.
For detail description see chapter Modbus protocol.
7.3.4 ModemIniString [-]
In case that your modem needs additional initialization e.g. AT commands, it can be entered here.
Otherwise leave this setpoint blank.
7.3.5 ModbusComSpeed [9600, 19200, 38400, 57600]
If the Modbus mode is selected on COM1 or COM2 channels, the Modbus communication speed in
bps can be adjusted here.
HINT
In case of ModBus/TCP communication via IB-Lite communication module is automatically adjusted
COM1 Mode=DIRECT, COM2=MODBUS and ModbusComSpeed=57600. There isn’t required any
other additional setting (of course except IB-Lite setpoints, see below)
7.3.6 IBLite IP Addr [-]
IP address of IB-Lite module
7.3.7 IBLite NetMask [-]
IB-Lite network mask
