InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
7.4.16 D+ function [ENABLED, CHRGFAIL, DISABLED]
ENABLED: The D+ terminal is used for both functions - “running engine” detection and charge fail
detection.
CHRGFAIL: The D+ terminal is used for charge fail detection only.
DISABLED: The D+ terminal is not used. Default state.
HINT
The magnetization current is provided independently on this setpoint value.
The D+ charge fail protection becomes active after Engine params: Idle time reaches zero.
7.4.17 ECU Control [ENABLED, DISABLED]
The setpoint enables adjustment of the electronic engine control by following settings.
ENABLED: There is a full available control of an electronic engine given by the setting of the ECU
unit of the engine, i.e. Start request, Stop request, Speed request are enabled if
available. Default state.
DISABLED: Control of an electronic engine is fully blocked and the InteliDrive Lite can only monitor
the values of an electronic engine.
7.4.18 ECU SpeedAdj [RPM]
Enables to adjust engine speed in ECU via CAN bus. Speed request value after the Idle time is over
and no other speed selection is activated.
Speed request in % range is calculated using the setpoints 0%ofSpeedReq and 100%ofSpeedReq.
Step: 1RPM
Range: MinSpeedLim - MaxSpeedLim
Default value: 1500RPM
7.4.19 RetToSpeedAdj [DISABLED, ENABLED]
Selection among LBI Speed Sel1, 2, 3 behavior.
DISABLED: Speed request is set by LBI Speed Sel1, 2, 3 (see appropriate setpoints) by rising
edge (button, no switch) - i.e. Speed request stay constant after the input is opened
and can be changed by BI Speed Up and Speed Down. Default state.
ENABLED: Speed request goes to ECU SpeedAdj when the LBI Speed Sel1, 2, 3 are opened.
Speed request can be changed by Binary inputs Speed Up and Speed Down when
LBI Speed Sel1, 2, 3 are closed.
7.4.20 MinSpeedLim [RPM]
The setpoint presets the minimum engine speed in the “Running” operation state. Also see other
conditions in the chapter below.
Step: 1RPM
Range: Starting RPM - MaxSpeedLim
Default: 1200RPM
