ComAp InteliDrive Lite - Counter Mode 1, Counter Mode 2; AIO Module; Anlinaio1, AIO2, AIO3, AIO4 Lev1 [ ]; Anlinaio1, AIO2, AIO3, AIO4 Lev2 [ ]

InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
110
LiteEdit
429496729,4
Continue from 0,0
Step: 0,01
Range: 0,01 - +655,34
Default: 1,00
7.9.4 Counter mode 1, Counter mode 2
Setting of Counter 1 and Counter 2 mode:
Always: Corresponding counter counts pulses all time.
Running: Corresponding counter counts pulses only when engine is running.
OFF: Corresponding counter does not count pulses. Default settings.
HINT
The Total 1 and Total 2 values are visible in LiteEdit – Values – Statistics.
The Total 1 and Total 2 values disappear from controller screen when both Counter modes 1 and 2
are switched OFF otherwise there is new screen between existing Statistics and Alarm list.
7.10 AIO module
7.10.1 AnlInAIO1, AIO2, AIO3, AIO4 lev1 [ ]
The level for IL-NT-AIO plug-in card Analog input 1, 2, 3, 4 alarm detection.
Step: 1
Range: -100 - +10000
Default: 0
7.10.2 AnlInAIO1, AIO2, AIO3, AIO4 lev2 [ ]
The level for IL-NT-AIO plug-in card Analog input 1, 2, 3, 4 alarm detection.
Step: 1
Range: -100 - +10000
Default: 0
7.10.3 AnlInAIO1, AIO2, AIO3, AIO4 del [s]
Delay for IL-NT-AIO plug-in card Analog input 1, 2, 3, 4 alarm.
Step: 1s
Range: 0 - 180s
Default: 5s
HINT
Plug-in analog inputs protection alarms can be configured following way
Configuration
Protection
