ComAp InteliDrive Lite - AIN7 Highsd [ ]; AIN7 Highdel [S]; AIN8 Level 1 [ ]; AIN8 Level 2 [ ]

InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
103
7.7.59 AIN7 HighSd [ ]
High ShutDown limit level for AIN7
Step: 1
Range: 0 - 10000
Default: 10
7.7.60 AIN7 HighDel [s]
High level protection delay for Wrn and Sd of AIN7
Step: 1s
Range: 0 - 3600s
Default: 10s
HINT
In the alarm list is only displayed Wrn/Sd alarm on the appropriate analog input. There is not
resolution Low/High alarm.
NOTE:
Analog input 7 is fully configurable and it is voltage type of input with range 0-10V
7.7.61 AIN8 Level 1 [ ]
Warning limit level for AIN8
Step: 1
Range: 0 - 10000
Default: 20
7.7.62 AIN8 Level 2 [ ]
Shutdown limit level for AIN8
Step: 1
Range: 0 - 10000
Default: 10
7.7.63 AIN8 Del [s]
Delay for Wrn/Sd AIN8 alarm.
Step: 1s
Range: 0 - 3600s
Default: 10s
NOTE:
Analog input 8 is configurable with basic two levels protection and it is voltage type of input with range
0-10V.
