ComAp InteliDrive Lite Reference Guide

InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
100
7.7.41 AIN6 Level 1 [ ]
Warning limit level for AIN6
Step: 1
Range: 0 - 10000
Default: 20
7.7.42 AIN6 Level 2 [ ]
Shutdown limit level for AIN6
Step: 1
Range: 0 - 10000
Default: 10
7.7.43 AIN6 Del [s]
Delay for Wrn/Sd AIN6 alarm.
Step: 1s
Range: 0 - 3600s
Default: 10s
7.7.44 AIN6 Eval [NORMAL, CLASS C]
NORMAL: Protection behaves according to the standard configuration of Wrn/Sd alarm in
LiteEdit AINx configuration screen. Default state.
CLASS C: The protection is type “Running only” and does not depend on Running only tick in
LiteEdit AINx Alarm properties configuration window. Protection (Class C) is working
after AINx Del or sooner when appropriate value increases over AINx Wrn limit +3
seconds - after engine start. Warning/ShutdDown protection is activated with fix delay
0,5s.
HINT
Class C protection is working and corresponding setpoints are visible only when corresponding AIN is
configured in Modify->Alarm properties-> Direction-> Window prot.
7.7.45 AIN6 LowWrn [ ]
Low Warning limit level for AIN6
Step: 1
Range: 0 - 10000
Default: 20
7.7.46 AIN6 LowSd [ ]
Low ShutDown limit level for AIN6
Step: 1
Range: 0 - 10000
Default: 10
