ComAp InteliDrive Lite Reference Guide

InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
143
14 Technical data
14.1 Power supply
Power supply range 8-36VDC
Power supply drop-out immunity 100ms from min. 10V return to min. 8V
Power consumption 40-440mA depend on supply voltage and temperature
Consumption depends on supply voltage 0,104A at 8VDC
0,080A at 12VDC
0,051A at 24VDC
0,044A at 30VDC
0,040A at 36VDC
Battery voltage measurement tolerance 2 % at 24V
HINT
For the supply voltage less than 7V the backlight of the display is switched off. Short-term voltage
drops (e.g. during the engine cranking) do not affect the operation at all.
14.2 Operating conditions
Operating temperature InteliDrive Lite -20 +70°C
Operating temperature InteliDrive Lite LT -40 +70°C
Storage temperature -30 +80°C
Protection front panel IP65
Humidity 95% without condensation
Standard conformity
Low Voltage Directive EN 61010-1:95 +A1:97
Electromagnetic Compatibility EN 50081-1:94, EN 50081-2:96
EN 50082-1:99, EN 50082-2:97
Vibration 5 - 25 Hz, ±1,6mm
25 - 100 Hz, a = 4 g
Shocks a = 200 m/s
2
14.3 Low Temperature modification
LCD display limits range for controller operating temperature: from -20°C to +70°C, even if the other
electronic components work in wider temperature range.
Internal preheating foil is mounted in InteliDrive Lite LT to extend display operational temperature
range. Preheating starts at temperature below 5°C and preheating power depends on temperature
and power supply voltage.
Preheating foil increases controller current consumption
Controller
consumption at
No preheating
Preheating at ambient temperature
0
o
C
-20
o
C
-40
o
C
