ComAp InteliDrive Lite Reference Guide

InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
118
Active input opens the binary output Ready to Load during the engine running state. Ready to Load
can be closed back (if other conditions are fulfilled – see the Ready to Load binary output description)
if Nominal/Idle is opened.
9.3.16 Speed Up
If the input is active, the Speed Request may increase the engine speed value. The Speed Request
value may also depend on the conditions which are described in the chapter below.
9.3.17 Speed Down
If the input is active, the Speed Request may decrease the engine speed value. The Speed Request
value may also depend on the conditions which are described in the chapter below.
Speed Up/Down binary inputs are active only when Regulator: LAI SpdSelect = OFF.
9.3.18 Speed Sel1
If the input is active, the Speed request = Engine params: BI Speed Sel1 setpoint. The function is
affected by Engine params: RetToSpeedAdj.
9.3.19 Speed Sel2
If the input is active, the Engine params: BI Speed Sel2 setpoint may give the engine speed value for
Speed request to an ECU engine. The Speed Request value may also depend on the conditions
which are described in the chapter below.
9.3.20 Speed Sel3
If the input is active, the Engine params: BI Speed Sel3 setpoint may give the engine speed value for
Speed request to an ECU engine. The Speed Request value may also depend on the conditions
which are described in the chapter below.
HINT
Engine params: RetToSpeedAdj = DISABLED, Speed request is adjusted by BI Speed Sel1, 2, 3
edge (button press), i.e. input can be opened and Speed request stay constant.
HINT
Engine params: RetToSpeedAdj = ENABLED, Speed request is adjusted by BI Speed Sel1, 2, 3 level
(switch), i.e. when input is opened Speed request go back to Engine params: ECU SpeedAdj level.
HINT
SpeedSel1, 2,.3 binary inputs are active only when Regulator: LAI SpdSelect = OFF.
NOTE:
When more binary inputs are active at the same time, e.g. all binary inputs: ‘Speed Sel1’, ‘Speed
Sel2’, ‘Speed Sel3’ then requested speed is given by Engine params: BI Speed Sel 1 (lowest index)
setpoint.
9.3.21 Lang selection
Switch display texts between two languages.
