CDM-840 Remote Router MN-CDM840

Ethernet-based Remote Product Management Revision 3

6–32

6.3.3.2.2 Configuration | WAN | Mod (Modulator) Pages

Click the Config, ACM, or DPC tab to continue.

6.3.3.2.2.1 Configuration | WAN | Mod | Config

Use this page to configure CDM-840 Tx modulator operations.

Figure 6-18. Configuration | WAN | Mod | Config Page

Modulator
