Comtec CDM-840 - Entry Channel Mode (ECM) Commands and Queries

CDM-840 Remote Router MN-CDM840
Serial-based Remote Product Management Revision 3
7–32
7.3.13 Entry Channel Mode (ECM) Commands and Queries
Parameter
Type
Command
(Instruction
Code
& Qualifier)
Number of
Arguments for
Command or
Response to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code &
Qualifier)
Response to Query
(Target to Controller)
ECM Mode
EMD=
1 byte
Command or Query.
Sets or returns ECM Mode in the form x, where:
0=Disable
1=Offline
2=Wait
3=Online
EXAMPLE: <0/EMD=0[cr]
EMD=
EMD?
EMD*
EMD#
EMD?
EMD=x
(see Description
of Arguments)
TX Base
Power
EBP=
4 bytes
Command or Query.
Sets or returns the Tx Base power in the form sxxx, where:
s=sign [– (negative) or + (positive)]
xxx=power value from -400 to 0 in 0.1dB increments
EXAMPLE: <0/EBP=-252[cr] (sets Tx Base power @ -25.2dB)
EBP=
EBP?
EBP*
EBP#
EBP?
EBP=sxxx
(see Description
of Arguments)
ECM
Multicast
Address
EMI=
15 bytes
Command or Query.
Sets or returns the IP Address for the VMS Multicast IP in the form
xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx=the IP Address
EXAMPLE: <0/EMI=192.168.001.004[cr]
EMI=
EMI?
EMI*
EMI#
EMI?
EMI=xxx.xxx.xxx.xxx
(see Description
of Arguments)
ECM Group
ID
EGI=
3 bytes
Command or Query.
Sets or returns the ECM Group ID in the form xxx, where:
xxx=value from 0 to 255
EXAMPLE: <0/EGI=100[cr]
EGI=
EGI?
EGI*
EGI#
EGI?
EGI=xxx
(see Description
of Arguments)
ECM Mode
Power Hunt
Function
EPH=
1 byte
Command or Query.
Sets or returns the Power Hunt function when in ECM Mode in the form x,
where:
0=Disabled
1=Enabled
EXAMPLE: <0/EPH=1[cr]
EPH=
EPH?
EPH*
EPH#
EPH?
EPH=x
(see Description
of Arguments)
RX LO
Frequency
ERF=
5 bytes
Command or Query.
Sets or returns the RX LO frequency value in the form xxxxx, where:
xxxxx=value in MHz.
EXAMPLE: <0/ERF=02300[cr]
ERF=
ERF?
ERF*
ERF#
ERF?
ERF=xxxxx
(see Description
of Arguments)
TX LO
Frequency
ETF=
5 bytes
Command or Query.
Sets or returns the TX LO frequency value in the form xxxxx, where:
xxxxx=value in MHz
EXAMPLE: <0/ETF=02300[cr]
ETF=
ETF?
ETF*
ETF#
ETF?
EBP=xxxxx
(see Description
of Arguments)
