Comtec CDM-840 - CDM-840 Header and Payload Compression Operation

CDM-840 Remote Router MN-CDM840
Appendix H Revision 3
H–4
H.2 CDM-840 Header and Payload Compression Operation
The CDM-840 provides several means for configuring Header and Payload Compression Carrier
ID operation via Remote Product Control with a user-supplied PC:
• CDM-840 HTTP (Web Server) Interface using a compatible Web browser.
• Ethernet-based Simple Network Management Protocol (SNMP) using a Network
Management System (NMS) and Management Information Base (MIB) File Browser.
• Serial-based Remote Control Interface using a terminal emulation program or Windows
Command-line.
COMTECH EF DATA RECOMMENDS USE OF THE ETHERNET-BASED SNMP INTERFACE
AND SERIAL-BASED REMOTE CONTROL INTERFACE ONLY FOR ADVANCED USERS.
COMTECH EF DATA STRONGLY ENCOURAGES USE OF THE CDM-840 AND CDD-880
HTTP INTERFACES FOR MONITOR AND CONTROL (M&C) OF THE CDM-840 OR
CDD-880.
THE SERIAL AND HTTP INTERFACE FIGURES FEATURED THROUGHOUT THIS CHAPTER
ARE INTENDED FOR USER REFERENCE ONLY AND ARE SUBJECT TO CHANGE. THE
FIRMWARE INFORMATION (I.E., REVISION LETTERS, VERSION NUMBERS, ETC.) AS
DISPLAYED MAY DIFFER FROM YOUR SETUP.
H.2.1 Compression Operation – CDM-840 HTTP Interface
See Chapter 6. ETHERNET-BASED REMOTE PRODUCT MANAGEMENT for in-depth
information about the function and operation of the CDM-840 HTTP Interface.
YOU MAY PROCEED WITH ETHERNET-BASED REMOTE PRODUCT MANAGEMENT
(HTTP OR SNMP), ASSUMING THAT:
• YOUR CDM-840 IS OPERATING WITH THE LATEST VERSION FIRMWARE FILES.
• YOUR CDM-840 IS CONNECTED TO A USER-SUPPLIED, WINDOWS-BASED PC AS
FOLLOWS:
O THE PC SERIAL PORT IS CONNECTED TO THE CDM-840 REAR PANEL
‘CONSOLE’ PORT WITH A USER-SUPPLIED SERIAL CABLE.
O THE PC ETHERNET PORT IS CONNECTED TO THE CDM-840 REAR PANEL
‘ETHERNET | MANAGEMENT | FE ETHERNET’ 10/100 FAST ETHERNET PORT
WITH A USER-SUPPLIED HUB, SWITCH, OR DIRECT ETHERNET CABLE
CONNECTION.
O THE PC IS RUNNING A TERMINAL EMULATION PROGRAM (FOR OPERATION
OF THE CDM-840 SERIAL INTERFACE) AND A COMPATIBLE WEB BROWSER
