CDM-840 Remote Router MN-CDM840
Appendix J Revision 3
J–5
• Each QoS Group supports these QoS Control Modes:
o Max/Pri (Maximum/Priority) – Provides multi-level traffic prioritization with the ability
to limit maximum traffic per priority class. See Sect. J.2.2.1 for details.
o Min/Max (Minimum/Maximum) – Provides a Committed Information Rate (CIR) to
each user defined class of traffic with the ability to allow a higher rate (MIR) depending
on bandwidth availability. See Sect. J.2.2.2 for details.
o Pri-Weighted (Priority/Weighted) – Allows for a combination of priorities and weights
with CIR. See Sect. J.2.2.3 for details.
o DiffServ (Differentiated Services) – Industry-standard method that enables seamless co-
existence in networks that implement DiffServ. See Sect. J.2.2.4 for details.
• Associates Remotes to QoS Groups for ACM/VCM.
An incoming packet is mapped to a QoS Group based on:
• Matching Subnet;
• Matching VLAN.
The system collects extensive statistics that can be used to monitor performance in real time, or
stored for historical analysis. This includes the entire Return Statistics; QoS Group Statistics; and
Per-Rule Statistics. See Sect. J.5 for details.
J.1.4 QoS Operation via Remote Product Control
The CDM-840 provides several means for configuring QoS operation via Remote Product Control
with a user-supplied PC:
• CDM-840 HTTP (Web Server) Interface using a compatible Web browser.
• Ethernet-based Simple Network Management Protocol (SNMP) using a Network
Management System (NMS) and Management Information Base (MIB) File Browser.
Chapter 6. ETHERNET-BASED REMOTE PRODUCT MANAGEMENT
YOU MAY PROCEED WITH ETHERNET-BASED REMOTE PRODUCT MANAGEMENT
(HTTP OR SNMP), ASSUMING THAT:
• YOUR CDM-840 IS OPERATING WITH THE LATEST VERSION FIRMWARE FILES.
• YOUR CDM-840 IS CONNECTED TO A USER-SUPPLIED, WINDOWS-BASED PC AS
FOLLOWS:
