CDM-840 Remote Router MN-CDM840
Serial-based Remote Product Management Revision 3
7–22
7.3.9 Unit Parameters Commands and Queries
Parameter
Type
Command
(Instruction
Code
& Qualifier)
Number of
Arguments for
Command or
Response to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code &
Qualifier)
Response to Query
(Target to Controller)
Equipment ID
N/A
37 bytes
Query only.
Returns the equipment ID and installed options in the form
AAAAssssBCDEFGHIJKsssssssssssssssssss, where:
AAAA=The modem model number (default 0840)
ssss (4 spares)=Installed hardware (default 0000)
BCDEFGHIJKsssssssssssssssssss=Software FAST options, where:
B=Tx Data/Symbol Rate option:
0=Standard: CCM 16 kbps to 256 kbps
1=CCM 16 kbps to 512bps
2=CCM 16 kbps to 1024 kbps
3=CCM 16 kbps to 2048 kbps
4=CCM 16 kbps to 5 Mbps
5=CCM 16 kbps to 10 Mbps
6=CCM 16 kbps to 15 Mbps
7=ACM 37 ksps to 100 ksps (future)
8=ACM 37 ksps to 200 ksps (future)
9=ACM 37 ksps to 400 ksps (future)
A=ACM 37 ksps to 800 ksps (future)
B=ACM 37 ksps to 1200 ksps (future)
C=ACM 37 ksps to 2400 ksps (future)
D=CCM 37 ksps to 4100 ksps (future)
C=Rx Data/Symbol Rate option:
0=Standard: CCM 1 Mbps to 15 Mbps
1=CCM 1 Mbps to 45 Mbps
2=CCM 1 Mbps to 100 Mbps
3=CCM 1 Mbps to 140 Mbps
4=CCM 1 Mbps to 167 Mbps
5=ACM 1 Msps to 5 Msps (future)
6=ACM 1 Msps to 15 Msps (future)
7=ACM 1 Msps to 34 Msps (future)
8=ACM 1 Msps to 47 Msps (future)
9=ACM 1 Msps to 62 Msps (future)
N/A
EID?
EID=AAAAssssBCDEFGHIJ
Ksssssssssssssssssss
(see Description of
Arguments)
