CDM-840 Remote Router MN-CDM840
Serial-based Remote Product Management Revision 3
7–17
7.3.5 Transmit (Tx) BERT Command or Query
Parameter
Type
Command
(Instruction
Code
& Qualifier)
Number of
Arguments for
Command or
Response to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code &
Qualifier)
Response to Query
(Target to Controller)
Tx BERT
State
BTX=
1 byte
Command or Query.
Sets or returns Tx BERT State in the form x, where:
0=Off
1=On
EXAMPLE: <0/BTX=1[cr]
BTX=
BTX?
BTX#
BTX?
BTX=x
(see Description of
Arguments)
7.3.6 Receive (Rx) BERT Command or Query
Parameter
Type
Command
(Instruction
Code
& Qualifier)
Number of
Arguments for
Command or
Response to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code &
Qualifier)
Response to Query
(Target to Controller)
Rx BERT
State
BRX=
1 byte
Command or Query
Sets or returns Rx BERT state in the form x, where:
0=Off
1=On
EXAMPLE: <0/BRX=1[cr]
BRX =
BRX?
BRX *
BRX #
BRX?
BRX=x
(see Description
of Arguments)
7.3.7 BUC (Block Up Converter) Parameters Commands and Queries
Parameter
Type
Command
(Instruction
Code
& Qualifier)
Number of
Arguments for
Command or
Response to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code &
Qualifier)
Response to Query
(Target to Controller)
BUC
Attenuation
ATT=
4 bytes
Command or Query.
Sets or returns BUC attenuation level in the form xxxx, where:
xxxx=value from -1 to 3000 (in 1/100 dB), in 0.25 dB increments
EXAMPLE: <0/ATT=2[cr]
ATT=
ATT?
ATT*
ATT#
ATT?
ATT=xxxx
(see Description of
Arguments)
BUC FSK
Address
BAD=
2 bytes
Command or Query.
NOTE: FOR USE ONLY WITH BUCS THAT SUPPORT FSK.
Sets or returns BUC Address in the form xx, where:
xx=value from 01 to 15
EXAMPLE: <0/BAD=1[cr]
BAD=
BAD?
BAD*
BAD#
BAD?
BAD=xx
(see Description of
Arguments)
