CDM-840 Remote Router MN-CDM840
Serial-based Remote Product Management Revision 3
7–18
Parameter
Type
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to Query
(Target to Controller)
Sets or returns the BUC Current High Limit in the form xxxx, where:
xxxx=value from 0 to 4000 mA, in 100 mA increments
(see Description of
Arguments)
Sets or returns the BUC Current Low Limit in the form xxxx, where:
xxxx=value from 0 to 4000 mA, in 100 mA increments.
EXAMPLE: <0/BCL=1200[cr]
(see Description of
Arguments)
Returns the value of the BUC DC current in the form xxxx, where:
xxxx=value from 0 to 9999 mA.
EXAMPLE: <0/BDC?[cr]
>0000/BDC=9999[cr][lf]
NOTE: If not available, response is 0000.
(see Description of
Arguments)
Returns the value of the BUC Voltage in the form xx.x, where:
xx.x=value from 0 to 64.0 Volts.
EXAMPLE: <0/BDV?[cr]
(see Description of
Arguments)
Sets or returns the BUC 10 MHz Reference control in the form x, where:
0=Off
1=On
(see Description of
Arguments)
Sets or returns the BUC output power enable in the form x, where:
0=Off
1=On
(see Description of
Arguments)
Returns the BUC output power level in the form xxx, where:
xxx=value from 0 to 999 dBm, in 0.1 dBm increments.
EXAMPLE: <0/BOL?[cr]
>0000/BOL=45[cr][lf] (returns 4.5 dBm).
RESPONSE NOTE: Returns 0 when FSK and BUC power are not enabled.
(see Description of
Arguments)
