CDM-840 Remote Router MN-CDM840
Ethernet-based Remote Product Management Revision 3
6–49
6.3.3.2.5 Configuration | WAN | Compression
Use this page to configure the Payload and Header Compression feature, if enabled.
Figure 6-23. Configuration | WAN | Compression Page
Click the (Link to Compression Statistic page) hyperlink to access the Status | Statistics |
Compression page (Sect.
6.3.4.1.3).
Refresh Rates
Enter each refresh rate, from 1 to 600 packets or 1 second (whichever comes first). From left to
right:
Feature Description
Header Compression for UDP User Datagram Protocol refresh rate
Header Compression for RTP
Real Time Protocol refresh rate
Header Compression for all others
Default protocol refresh rate
Payload Compression refresh rate
Set the desired rates. Click [Submit] to save.
Bridge Point-to-Multipoint (BPM) Mode Configuration
Use the drop-down lists to Enable or Disable Payload and Header Compression for all of the
transmitted packets when operating in Bridge Point-to-Multipoint (BPM) Mode. Click [Submit]
to save.
In Managed Switch Mode, the selected Compression modes apply to all traffic.
