7.3.3 Receive (Rx) Parameters Commands and Queries
Parameter
Type
Command
(Instruction
Code
& Qualifier)
Number of
Arguments for
Command or
Response to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code &
Qualifier)
Response to Query
(Target to Controller)
Rx
Frequency
RFQ=
10bytes
Command or Query.
Sets or returns Rx Terminal Frequency, in MHz, being received from the
satellite in the form xxxxx.xxxx, where:
xxxxx.xxxx=value from 950.0000 to 65000.0000 MHz (L-Band), in 100 Hz
increments.
NOTES:
1) If RX LO=00000, then the Rx Frequency is entered as L-Band direct –
950.0000 to 2150.0000;
2) If RX LO is set in the range of 30000 to 65000, the Rx Frequency is ±Rx
LO, and this will be the resulting L-Band frequency the modem will expect
to receive.
RFQ=
RFQ?
RFQ*
RFQ#
RFQ?
RFQ=xxxxx.xxxx
(see Description of
Arguments)
Rx Gold
Code
Sequence
Index
N/A
6 bytes
Command or Query.
NOTE: VALID ONLY IN DVB-S2 MODE
Sets or returns Rx Gold Code Sequence Index in the form xxxxxx, where:
xxxxxx=value from 0 to 262141
EXAMPLE: <0/RGS=189063[cr]
RGS=
RGS?
RGS*
RGS#
RGS?
RGS=xxxxxx
Rx
MODCOD
RMC=
2 bytes
Command or Query.
Sets or returns Rx Demodulation in the form xx, where:
0=reserved
1=QPSK 1/4
2=QPSK 1/3
3=QPSK 2/5
4=QPSK 1/2
5=QPSK 3/5
6=QPSK 2/3
7=QPSK 3/4
8=QPSK 4/5
9=QPSK 5/6
10=QPSK 8/9
11=QPSK 9/10
12=8PSK 3/5
13=8PSK 2/3
14=8PSK 3/4
15=8PSK 5/6
16=8PSK 8/9
17=8PSK 9/10
RMC?
RMC*
RMC#
RMC?
RMC=xx
(see Description of
Arguments)
