CDM-840 Remote Router MN-CDM840
Serial-based Remote Product Management Revision 3
7–15
Parameter
Type
Command
(Instruction
Code
& Qualifier)
Number of
Arguments for
Command or
Response to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code &
Qualifier)
Response to Query
(Target to Controller)
Rx
MODCOD
(cont.)
18=16-APSK 2/3
19=16-APSK 3/4
20=16-APSK 4/5
21=16-APSK 5/6
22=16-APSK 8/9
23=16-APSK 9/10
24=32-APSK 3/4
25=32-APSK 4/5
26=32-APSK 5/6
27=32-APSK 8/9
28=32-APSK 9/10
29=auto (ACM only)
All other codes are invalid.
EXAMPLE: <0/RMC=6[cr]
Rx
Spectrum
Invert
N/A
1 byte
Query only.
Returns Rx Spectrum Invert in the form x, where:
0=Normal
1=Rx Spectrum Inverted
EXAMPLE: <0/RSI?[cr]
>0000/RSI=1[cr][lf]
RSI?
RSI*
RSI#
RSI?
RSI=x
(see Description of
Arguments)
Rx Symbol
Rate
RSR=
10 bytes
Command or Query.
Sets or returns Rx Symbol Rate in the form dddddd.ddd, where:
dddddd.ddd=value, in ksps, from 16ksps to 4.5Msps
EXAMPLE: <0/RSR =002047.999[cr]
RSR=
RSR?
RSR *
RSR #
RSR?
RSR =dddddd.ddd
(see Description of
Arguments)
