CDM-840 Remote Router MN-CDM840
Rear Panel Connections Revision 3
3–6
3.2.1 IF Connector Group
CAUTION – THERE MAY BE DC VOLTAGES PRESENT ON THE TYPE ‘N’ TX AND RX IF
CONNECTORS, UP TO A MAXIMUM OF 48 VOLTS. THE CONNECTOR LED LABELED ‘DC!’
WILL LIGHT TO INDICATE THIS CONDITION.
3.2.1.1 ‘L-BAND Rx’ IF Connector
3.2.1.2 ‘L-BAND Tx’ IF Connector
Connector Type
Name
Description
Direction
50Ω Type ‘N’ Female L-BAND Rx Rx IF Signal, L-Band In
Connector Type
Name
Description
Direction
50Ω Type ‘N’ Female L-BAND Tx Tx IF Signal, L-Band Out
