Comtec CDM-840 - Specifications; Product Features; Physical, Power, and Environmental

CDM-840 Remote Router MN-CDM840
Introduction Revision 3
1–10
1.4 Specifications
1.4.1 Product Features
Item
Description
Front Panel
8 Light-Emitting Diodes (LEDs):
UNIT STATUS (Green/Amber/Red)
STORED EVENT (Amber)
ONLINE (Green)
TEST MODE (Amber)
TRANSMITTER ON (Green/Red)
Tx TRAFFIC (Green/Amber/Red)
Rx TRAFFIC (Green/Amber/Red)
GE LINK/ACTIVITY (Green)
Rear Panel IF
Connectors / Impedance
Tx
Type ‘N’ female connectors, 50Ω
Rx
Rear Panel Data Interface
Connectors
• 1X RJ-45 female port for 10/100/1000 BaseT Gigabit Ethernet data traffic
• 1X RJ-45 female port for 10/100 BaseT Fast Ethernet HTTP and SNMP product
management
• 1X DB-9M EIA-232 connector for serial remote monitor and control
• 1X DB-9F EIA-232 connector for 1:1 or 1:N redundancy switch operation
• 1X DB-15M connector for Form C unit alarms
• 2X Type ‘BNC’ female connectors for optional G.703 E1, 2.048 Mbps (Unbalanced
75Ω)
Packet Processor Supported
Protocols
RFC 768 – UDP
RFC 791 – IP
RFC 792 – ICMP
RFC 793 – TCP
RFC 826 – ARP
RFC 856 – Telnet
RFC 862 – Ping
RFC 894 – IP
RFC 959 – FTP
RFC 1112 – IP Multicast
RFC 1213 – SNMP MIB II
RFC 1812 – IPv4 Routers
RFC 2045 – MIME
RFC 2474 – DiffServ
RFC 2475 – DiffServ
RFC 2578 – SMI
RFC 2597 – AF PHB
RFC 2598 – Expedite Forwarding
RFC 2616 – HTTP
RFC 3412 – SNMP
RFC 3416 – SNMPv2
RFC 3418 – SNMP MIB
Packet Processor Statistics
Detailed packet and throughput statistics
1.4.2 Physical, Power, and Environmental
Parameter
Specifications
Physical Dimensions
1RU high x 19.0 inches wide x 16.1 inches deep
(4.4 cm h x 48 cm w x 40.8 cm d) approximate
Weight
3.2 kg (7 lbs)
Power Supply
AC
100V to 240V AC, 47 to 63 Hz, IEC 320 input
DC (HW Option)
-48V (36V to 60V) DC
Power Consumption
60 W typical
Fuse
AC
120/230 V AC: T3.15A, Slo-Blo 20 mm
DC (HW Option)
-48V DC (38 to 60 V DC): T8.0A, Slo-Blo 20 mm
Temperature
Operating
0° to 50°C (32° to 122°F)
Storage
-20° to 70°C (-4° to 158°F)
Humidity
95% maximum, non-condensing
