Comtec CDM-840 - Remote Commands and Queries

CDM-840 Remote Router MN-CDM840
Serial-based Remote Product Management Revision 3
7–9
7.3 Remote Commands and Queries
7.3.1 Table Indexes
Notes:
1) Index Columns – Where Column ‘C’=Command, and Column ‘Q’=Query, columns marked ‘X’ designate the instruction code as
Command only, Query only, or Command or Query.
2) In the tables that follow, the following codes are used in the ‘Response to Command’ column (see Sect. 7.2.2.5.2
):
= Message ok
# Message ok, but unit is not in Remote mode.
? Received ok, but invalid arguments were found. ~ Time out of a pass-through message, either to via EDMAC or a local ODU
^ Message ok, but unit is in Ethernet mode.
Sect. 7.3.2 Transmit (Tx) Parameters Commands and Queries
CODE C Q PAGE
CODE C Q PAGE CODE C Q PAGE
TAR
X X
7-12 TMC
X X
7-12 TSR
X X
7-13
TDR
X
7-12 TPL
X X
7-13 TXO
X X
7-13
TFQ
X X
7-12 TSI
X X
7-13 VFQ
X
7-13
Sect. 7.3.3 Receive (Rx) Parameters Commands and Queries
CODE C Q PAGE
CODE C Q PAGE CODE C Q PAGE
RFQ
X X
7-14 RSI
X
7-15
RGS
X X
7-14
RSR
X X
7-15
RMC
X
7-14
Sect. 7.3.4 Demodulator Parameters Commands and Queries
CODE C Q PAGE
CODE C Q PAGE CODE C Q PAGE
ESN
X
7-16
RSL
X
7-16
