CDM-840 Remote Router MN-CDM840

Introduction Revision 3

1–8

1.3.3.2.1 Rear Panel Standard Features

As per Figure 1-5, from left to right:

Power Interface:

• 100V to 240V AC Primary Input Power Supply with Press-fit Fuse Holder

IF Interfaces:

• (2X) Type ‘N’ female L-BAND Rx (at far left) and L-Band Tx (at far right) connectors for 50Ω

L-Band (950 to 2150 MHz)

Utility and Traffic Data Interfaces:

• (1X) RJ-45 ETHERNET | TRAFFIC | GE 10/100/1000 BaseT Gigabit Ethernet port for Ethernet

traffic.

• (1X) RJ-45 ETHERNET | MANAGEMENT | FE 10/100 BaseT Fast Ethernet port for Ethernet-

based management and control purposes (HTTP and SNMP).

• (1X) DB-9M EIA-232 CONSOLE connector for serial remote control.

• (1X) DB-15M EIA-232 ALARMS connector for I&Q Constellation/Rx AGC Monitor Output.

1.3.3.2.2 Rear Panel Optional Features

As per Figure 1-5, from left to right:

Optional Power Interfaces:

• -48V DC Primary Input Power Supply with Screw-in Fuse Holders

• 24V DC BUC 90 Watt Power Supply (AC Input or DC Input versions)

• 48V DC BUC 150 Watt Power Supply (AC Input or DC Input versions)

Optional data interfaces

• (2X) Type ‘BNC’ female connectors labeled “G.703 | IN / OUT” are provided for operation of

the optional G.703 E1 Interface/RAN Optimization FAST Feature upgrade.

Optional hardware operation:

• (1X) DB-9F EIA-232 REDUNDANCY connector for interoperability with a separately

purchased Comtech EF Data CRS-170A 1:1 L-Band Redundancy Switch.

Rear Panel Rack Support Brackets Kits are available from Comtech EF Data:

• KT-0000168 4” Rear-Mounting Support Brackets Kit

• KT-0000195 10” Rear-Mounting Support Brackets Kit

Sect. 2.2.1 Install the Optional Rear-Mounting Support Brackets Kit
