CDM-840 Remote Router MN-CDM840

Installation Revision 3

2–3

Feature

Description

Custom Rack Enclosure

2 CDM-840 Unit

3 Standard Rack Shelving

4 Rack Enclosure Threaded Front Rail (typical)

5 Unit Front Panel

6 User-supplied Screws

Figure 2-2. Install the Unit Into a Rack Enclosure

2.2.1 Install the Optional Rear Support Brackets Kit
