1.3 Features
1.3.1 Physical Description
The CDM-840 Remote Router is constructed as a 1RU-high rack-mounting chassis. Handles at
the front facilitate removal from and placement into a rack. The unit can be freestanding if
desired.
• Sect. 1.4 CDM-840 Specifications
• Sect. 2.1 Install the Unit Into a Rack Enclosure
1.3.1.1 Standard Assemblies
CEFD Item No. Description Where Installed
PL-0020642 CDM-840 Base AC Chassis Assembly –
PL-0000714 CDM-840 PCB Assembly In CDM-840 chassis
FS-0000030 Cartridge Fuse, 2.5A 250V AC 5x20mm Slo-Blo, 213 series In CDM-840 chassis
1.3.1.2 Optional Assemblies
CEFD Item No. Description Where Installed
PL-0000881
CDM-840 100-240V AC unit w/24V DC 90W @ 50°C BUC
Power Supply
In CDM-840 chassis
PL-0000883
CDM-840 100-240V AC unit w/48V DC 150W @ 50°C BUC
Power Supply
In CDM-840 chassis
PL-0020644 CDM-840 Base 48V DC Chassis Assembly –
PL-0000974
CDM-840 48V DC unit w/24V DC 90W @ 50°C BUC Power
Supply
In CDM-840 chassis
PL-0000975
CDM-840 48V DC unit w/48V DC 150W @ 50°C BUC Power
Supply
In CDM-840 chassis
KT-0000168 Rear-Mounting Support Bracket (4”)
Sides of CDM-840 chassis / rear
of user-supplied mounting rack
KT-0000195 Rear-Mounting Support Bracket (10”)
