CDM-840 Remote Router MN-CDM840
Ethernet-based Remote Product Management Revision 3
6–67
Statistics Control
Click [Clear Eth Stats], [Clear Mod Stats], [Clear Demod Stats], [Clear Drops (QoS Stats)], [Clear
All Stats], or [Refresh]. From left to right:
Click to clear entries from the Ethernet Statistics table.
Click to clear entries from the Mod Statistics table.
Click to clear entries from the Demod Statistics table.
[Clear Drops (QoS Stats)]
Click to clear the packets dropped in the Mod Statistics table.
Click to clear entries from all statistics tables on this page.
Click to update the contents of all tables on this page.
Ethernet Statistics
Typical for either the FE (ETHERNET | MANAGEMENT | FE) or GE (ETHERNET | TRAFFIC | GE)
ports, from left to right:
GE
Total Packets Transmitted
Total number of packets transmitted.
Total number of packets received.
Unicast packets transmitted.
Unicast packets received.
Multicast packets transmitted.
Multicast packets received.
Most recent transmitted data rate (in kilobits per second).
Most recently received data rate (in kilobits per second).
Peak transmitted data rate (in kilobits per second).
Peak received data rate (in kilobits per second).
Mod Statistics
From left to right:
Unicast packets transmitted.
Multicast packets transmitted.
Most recently transmitted symbol rate (in packets per second).
Most recently transmitted symbol rate (in kilobits per second).
Peak transmitted symbol rate (in kilobits per second).
Total number of bytes transmitted.
