The QoS Scheduler Calculation Solutions table for Case 3 / Example 1 is as follows:
Queue
Round 1
Round 2
Round ‘N’
Final kbps
Weight
Given
(kbps)
Leftover
(kbps)
Weight
Given
(kbps)
Leftover
(kbps)
Weight
Given
(kbps)
Leftover
(kbps)
1
9
12
–
–
–
–
–
–
–
12
2
8
10.672
–
–
–
–
–
–
–
10.672
3
7
9.328
–
–
–
–
–
–
–
9.328
4
6
8
–
–
–
–
–
–
–
8
Total ►
30
40
0
0
0
0
0
0
0
40
This table shows the result of the steps taken to calculate the individual allocated
bandwidths:
1. Calculate the bandwidth for each queue based on the total weight (30) and the available
bandwidth of 40 kbps (5000 bytes).
o Queue 1 = 5000 * (9 / 30) = 1500 bytes (12 kbps)
o Queue 2 = 5000 * (8 / 30) = 1334 bytes (10.672 kbps)
o Queue 3 = 5000 * (7 / 30) = 1166 bytes (9.328 kbps)
o Queue 4 = 5000 * (6 / 30) = 1000 bytes (8 kbps)
After Round 1, all bandwidth is consumed and the calculation loop stops.
Case 3 Example 1 Summary – Each queue’s share is as follows:
 Queue 1 = 1500 bytes (12 kbps)
 Queue 2 = 1334 bytes (10.762 kbps)
 Queue 3 = 1166 bytes (9.328 kbps)
 Queue 4 = 1000 bytes (8 kbps)
Case 3 / Example 2 – The Pri-Weighted QoS rules are configured as follows:
Queue
Min BW kbps (Bps)
Weight
Allowed BW kbps (Bps)
1
8 (1000)
9
–
2
16 (2000)
8
–
3
24 (3000)
7
–
4
32 (4000)
6
–
Total ►
80 (10000)
30
64 (8000)
Some of the weighted share is more than the minimum configured value. Each queue is
configured with minimum bandwidth and the weight as shown in the Case 3 / Example 2
rules table. The total allowed bandwidth is 8000 bytes per second.
