CDM-840 Remote Router MN-CDM840
Appendix J Revision 3
J–21
available, serving all service rates first. The total of all ASFD service rates are 1600 kbps,
which is less than the 2 Mbps leftover bandwidth.
o
After serving the service rates, the leftover bandwidth is 400 kbps. This 400 kbps will be
distributed to all ASFD classes equally in Round-robin fashion until either there is no
more bandwidth, or the input streams have no data.
o The resulting individual data rates are as follows:
Management 1 CS7 / b111000 200 kbps 9800 kbps 200 kbps
2 CS6 / b110000 800 kbps 9000 kbps 800 kbps
Voice 3 EXFD / b101110 1000 kbps 8000 kbps 1000 kbps
Video 3 CS5 / b101000 4000 kbps 4000 kbps 4000 kbps
Data-1 4 CS4 / b100000 550 kbps 3450 kbps 550 kbps
Data-2 5 CS3 / b011000 1450 kbps 2000 kbps 1450 kbps
Data-3 7 ASFD4 / b100010 1000 kbps N/A 100 + 100 kbps
Data-4 7 ASFD3 / b011010 1000 kbps N/A 400 + 100 kbps
Data-5 7 ASFD2 / b010010 1000 kbps N/A 500 + 100 kbps
Data-6 7 ASFD1 / b001010 1000 kbps N/A 800 + 100 kbps
Data-7 8 BE / bXXXXXX 2000 kbps N/A 0 kbps
