• Since ASFD 4 has the service rate 100 kbps, the excess 75 kbps will be given the other
queues where the service rate not met.
• In this case, the 75 kbps again will share equally among ASFD3, ASFD2, and ASFD1 since
these service rates were not met.
• The resulting individual data rate is as follows:
Stream Priority PHB / DSCP Code
Input Data Date
(kbps)
Leftover BW After
Serving the Queue
(kbps)
QoS Output Data
Rate (kbps)
Management 1 CS7 / b111000 200 9800 200
Networking
Control
2 CS6 / b110000 800 9000 800
Voice 3 EXFD / b101110 1000 8000 1000
Video 3 CS5 / b101000 4000 4000 4000
Data-1 4 CS4 / b100000 550 3450 550
Data-2 5 CS3 / b011000 1450 2000 1450
Data-3 7 ASFD4 / b100010 1000 N/A 100
Data-4 7 ASFD3 / b011010 1000 N/A 175 + 25
Data-5 7 ASFD2 / b010010 1000 N/A 175 + 25
Data-6 7 ASFD1 / b001010 1000 N/A 175 + 25
Data-7 8 BE / bXXXXXX 2000 N/A 0
Total ► 14000 0 8700
