CDM-840 Remote Router MN-CDM840
Installation Revision 3
2–5
• A medium Phillips screwdriver
• A 5/32-inch SAE Allen Wrench
• An adjustable Crescent wrench.
Do these steps to install the brackets kit (Figure 2-3):
Step Description
1
Assemble the Adapter Plates to the back sides of the CDM-840 chassis using the #10
2
Assemble the #10 Shoulder Screws through the Adapter Plate mounting slots using
the #10 Flat Washers, #10 Split Washers, and #10 Hex Nuts.
3
Mount the Rear Support Brackets to the rack enclosure threaded rear mounting
rails using the #10 Rack Bracket Bolts.
4
Slide the CDM-840 into the front of the rack enclosure. Make sure that the #10
Shoulder Screws properly engage into the slots of the Rear Support Brackets.
