CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Updating Firmware 4–4 MN-CDM570A
d. Identify the firmware information and Ethernet Traffic (M&C) IP Address using
one of the following methods:
• Chapter 6. FRONT PANEL OPERATION
• Chapter 7. ETHERNET-BASED REMOTE PRODUCT
MANAGEMENT
• Chapter 8. SERIAL-BASED REMOTE PRODUCT
MANAGEMENT
Using the CDM-570A/570AL Front Panel menus:
• Base Modem Firmware Info – Use the SELECT: UTIL  Firmware  Info
 Image#1 or Image#2  Bulk menu branches, as shown in this example:
Bulk#1: MM/DD/YY
FW-0020683* #.#.#
• Packet Processor Firmware Info – Use the SELECT: UTIL  Firmware 
Info
 PaP menu branches, as shown in this example:
PaP: MM/DD/YY
FW-0020781* #.#.#
• Ethernet IP Address – Use the CONFIG: Rem  Ethernet  Address
menu branch, as shown in this example:
Ether IP Address/Range:
192.168.001.011/24 ◄ ►,▲▼
