CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
ODU (Transceiver, BUC, LNB) Operation 10–21 MN-CDM570A
Additionally:
(KST CONFIG: ► KST RX:) LNB ► Band
LNB Rx Band:
A B C (◄ ►,ENT)
Use the ◄ ► arrow keys to select A, B, or C, and then press ENTER.
10.2.1.2.2.1.1.3 (KST SELECT: ► KST CONFIG:) Misc (Miscellaneous)
KST MISC: AGC Ref-Adjust
(◄ ►,ENT)
Use the ◄ ► arrow keys to select AGC or Ref-Adjust, and then press ENTER.
(KST CONFIG: ► KST MISC:) AGC
AGC MODE:
Off On Burst (◄ ►,ENT)
Use the ◄ ► arrow keys to select OFF, ON or BURST, and then press ENTER.
(KST CONFIG: ► KST MISC:) Ref-Adjust
Internal Ref Adjustment:
087 (▲ ▼,ENT)
To edit the INT 10MHz REF setting: Use the ▲▼arrow keys to select a value – the values
scroll from 000 to 255 – then press ENTER.
The INT REF is adjusted in the factory to be very accurate with the default
setting of 028. Use this feature as needed to compensate for the long-term
frequency drift of the oscillator.
10.2.1.2.2.1.2 (KST SELECT:) INFO (Information)
INFO:TX RX HPA LNA Equip
Assembly+SN FW (◄ ►,ENT)
For access to real-time, read-only information displays on the ODU currently in operation: Use the
◄ ► arrow keys to select TX, RX, HPA, LNA, Equip, Assembly+SN, or FW, and then press
ENTER.
(Displayed when ODU is KST-2000B unit)
