CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Front Panel Operation 6–67 MN-CDM570A
6.3.7.6 UTIL: VFD (Video Fluorescent Display Brightness)
Edit Display Brightness:
100% (▲ ▼,ENTER)
To adjust the display brightness, use the ▲▼arrow keys to select 25%, 50%, 75%, or 100%.
Press ENTER when the brightness is suitable.
6.3.7.7 UTIL: FW (Firmware Images)
Chapter 4. UPDATING FIRMWARE
THESE MENUS ARE INTENDED FOR DIAGNOSTIC PURPOSES ONLY. DO NOT
CHANGE AN IMAGE UNLESS OTHERWISE INSTRUCTED BY COMTECH EF DATA
PRODUCT SUPPORT.
Firmware Images:
Info Select (◄ ►,ENTER)
The modem can store two complete firmware images. This series of submenus display
information about the modem internal firmware, and allows selection of which firmware image
loads upon the next unit reboot.
Use the
◄ ► arrow keys to select Info or Select. Press ENTER.
6.3.7.7.1 (UTIL: FW Images) Info
The screen shots that follow are provided for example only. Your displays may
differ depending on your active firmware loads.
Firmware Info: Bootrom
Image#1 Image#2 PaP
Use the
◄ ► arrow keys to select a parameter. Press ENTER.
(UTIL: FW Info) Bootrom
Bootrom: MM/DD/YY
FW-0020684* #.#.#
(UTIL: FW Info) PaP
PaP: MM/DD/YY
FW-0020781* #.#.#
This screen is available only when the optional Packet Processor is installed:
