B.7.1 Field Upgrade Procedure – VersaFEC-2 Option Card

B.7.1.1 Overview

This section describes the field upgrade procedure you will need to follow to retrofit your CDM-570A/570AL with the optional VersaFEC-2

Option Card.

B.7.1.2 Requirements for Field Upgrade

• CDM-570A/570AL Satellite Modem

• Medium Phillips screwdriver

• CEFD P/N KT-0021134 VersaFEC-2 Option Card, containing:

CEFD Part Number

QTY

Description

PL-0022376

CDM-570A/570AL VersaFEC-2 Option Card

HW/SEM440X1/4PH

Screw, S.S., 4-40 x 1/4 LG, Pan Head Phillips
